CPF 650 Machine for sharpening the side angles on carbide-tipped circular saw blades

THE MACHINE CONCEPT

The CPF 650 is ideally equipped for sharpening carbide-tipped circular saw blades, offering versatility which leaves nothing to be desired.

  • Five CNC-controlled axes for beginning-to-end hydraulics-free complete machining of all commonly used angles – even for saws with group toothing
  • Oscillation grinding as standard – for high material removal rates in just one cycle, in line with the requirements for production and when replacing teeth during servicing
  • Optimal movement coordination for short grinding times and reduced non-productive times, adjustable feed cam for ideal tooth positioning
  • Proven VOLLMER drive technology for dynamic and reliable machining
  • Five-axis kinematics for maximum flexibility
  • Automatic central lubrication included in the basic equipment for reduced maintenance costs

THE APPLICATION

Side machining of saws for processing wood, plastics and aluminum. Its high level of flexibility and superior grinding efficiency makes the CPF 650 the first choice for many applications.

  • Automatic setting of all commonly used angles – including the hook angle – and automatic detection of the tooth pitch
  • Machining of convex tooth sides is also possible
  • Saw change possible without adjusting the mounting carriage – no need to set it up again

Machine for sharpening circular saws // VOLLMER CPF 650

CPF650
WORKPIECE DATA
CIRCULAR SAW BLADES
Circular saw blades with outside diameter 80 - 650 mm
Circular saw blades with bore diameter 10 - 180 mm
Circular saw blades with blade thickness ≤ 5 mm
TOOTH GEOMETRY
Grinding length on the side angles < 19 mm
Tangential clearance angle 0° - +8°
Radial clearance angle -20° - +6°
Hook angle -10° - +30°
Tooth pitch 6 - 100 mm
INTERFACES
Electrical connected load 4,9 kVA
INTERNAL COOLANT UNIT
Coolant tank 140 l
